Quilting Machine
Machine dimension(L*W*H): 5050mm*1600mm*2300mm
Quilting width: 2450mm
Number of pin rows: 3
Needle spacing: 3"+2";3"+3"(inches)
Pitch: 25.4mm
x-stroke: <305mm
Quilting thickness: ≤80mm
Needle step: 1-12mm
Production speed (m/h): 60-230(m/hour)
Needle model: 21#,22#,23#,24#
Quilting speed (rev/min): 1000(rev/min)
Voltage(AC): 380V/50HZ,220V/60HZ,3-Phase
Weight: 5100KG
Power: 8KW
1. The movement of needle row and pressure plate adopts aluminum alloy needle bar frame and pressure bar frame structure, which is oil-free and sturdy and durable;
2. It has 360-degree arbitrary quilting, unlimited independent pattern stepping functions, and automatic thread trimming function;
3. Independently developed "Yuteng Quilting System", which is compatible with embroidery DST files and is simple and easy to operate;
FEATURES
Easy to understand
Rich patterns
High quilting precision
One worker can operate it
One-year warranty
24-hour after-sales service
